Lightweight Automation Instrument Motors , Ac Synchronous Motor SNP AC 220v

Basic Information
Place of Origin: China
Brand Name: Hankscraft
Certification: ISO,Rohs,UL
Model Number: HK-33007A
Minimum Order Quantity: 1000 PCS
Price: Negotiable
Packaging Details: Carton box/Wooden box/Pallet
Delivery Time: 10 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100000 Pcs/ Week
Volage: 220-240V Frequency: 60/50HZ
Usage: Househould Appliance,Automation Instrument, Advertisement Power: Max 3 W
OEM: Acceptable RPM: 17+/-1
High Light:

permanent magnet stepper motor

,

permanent magnet electric motor

SNP AC 220V Automation Instrument Motor



Hankscraft has been producing motors since 1949 and has become an industry leader. Its products mainly include permanent magnet stepper motors,stepper reduction motors, hybrid stepper motors, DC brushed and brushless motors, synchronous motors, hysteresis Synchronous motors, etc.
Products are widely used in household appliances, HVAC valves, office equipment, security monitoring, sanitary ware and automotive parts.


Product name SNP AC 220V Automation Instrument Motor
Volage 220-240V
Frequency 60/50HZ
RPM 17+/-1
Usage Househould Appliance,Automation Instrument, Valve motor
Advertisement, Satellite antenna, Monitoring Euipment motor, Medical machine
Power 3W
Feature Small size, high torque, low noise, low power consumption,
high safety factor, long life
Insulation class B
Lead color White/Blue
Rotation CW
Motor life hour 50000 hrs
Packing Carton box







SNP AC 220V Automation Instrument Motor Feature



1. The rated voltage of the motor can start at 75%;
2. The motor must pass CE, TUV standard and Class B certification;
3. Noise and vibration requirements: Motor noise <39dB, and
4. No other abnormal noise at 30dB;
5. Lead: 22AWG 1015 105 ° C, terminal: 6.3 * 0.8 with insulation sleeve, temperature 105 ° C;
6. Compliance with ROHS.
7. Motor containing high temperature grease MS-54, temperature range -50 ~ 150 ° C.







Lightweight  Automation Instrument Motors , Ac Synchronous Motor SNP AC 220v 0






Our Advantages / Selling points





Company Profile





Hankscraft Plastic Division is a leader in plastic injection molding, whose partners are industrial leading companies, such as GE, GM. In the Plastic Division, we have different types of injection molding machines with tonnages ranging from 50T to 300T.



As a specialized manufacturer of molded thermoplastic products, we produce extremely tight tolerance parts in both high and low volume for wide applications. The main materials cover ABS, PA, PC. PS, PBT, PVC, PP. PE. PPO. PPR. POM, PPS and PET etc. For the secondary operations, we have sonic and rotary-welders. We also provide related services like resin selection, thermoplastic compounding, prototyping tooling, coating and painting.



Our products have been widely used in electronics, telecommunications, automobiles, household appliances etc. The company has acquired a good reputation through its excellent quality, reasonable price and good after sales services. We have a stable growing market share in all over the world.




FAQ



Q1. Are you a trading company or a manufacturer?
A:We are a manufacturer



Q2. I have no 3D drawing, how should I start the new project?
A : You can provide us a sample, we will help finish the 3D drawing design.



Q3. Before shipment, how to make sure the products quality?
A : We are specialized in high quality products. We have QC to inspect the products before each shipment. You can come to visit our factory or ask a third party for inspection. Or we can send you videos to show the production process



Q4. How could I pay them?
A : Paypal, Western Union, T/T, L/C are acceptable, so just let us know which is convenient for you.



Q5. When can I get the price?
A : We usually quote within 24 hours after we get your inquiry. If it is very urgent, please call us or tell us in your email so that we will regard your inquiry as priority.
